| pg. 9:7 Specifications |
Vehicle Loading
The tires on your Volvo should perform to specifications at all normal loads when inflated as recommended on the tire information label. The label is located on the rear-facing edge of the right-front door. This label lists both tire and vehicle design limits. Do not load your car beyond the load limits indicated.
WARNING!
|
All specifications are subject to change without notice.
Capacities
Fuel tank (approx.)
Wagon:
19.8 US gal.
75 liters
Sedan:
21.1 US gal.
80 liters
Cooling System
10.5 US qts.
10 liters
Engine
5.9 US qts. *
at oil change
5.75 liters
Engine,
5.5 US qts. *
excl. oil filter
5.15 liters
Automatic transmission
7.9 US qts.
7.5 liters
Rear axle
Wagon:
1.8 US qts.
1.7 liters
Sedan:
1.4 US qts.
1.3 liters
Power steering gear
0.8 US qts.
0.8 liter
* if oil cooler is drained, add 0.47 US qts (0.4 liter)
| pg. 9:8 Service manuals, Road assistance |
Service Manuals for your Volvo are available for purchase. These are the same manuals used by competent Volvo technicians.
Major sections within the Service Manual System include: 0-General Information; 1- Lubrication and Service; 2- Engine; 3- Electrical System; 4- Power Transmission; 5-Brakes; 6- Suspension and Steering; 7- Springs Shock Absorbers and Wheels; 8- Body and Interior.
A Literature Catalog Request Card was placed in the car prior to delivery from the retailer to you. Complete ordering information is provided
All specifications are subject to change without notice.
Volvo supports Voluntary Mechanic Certification by the A.S.E. Certified mechanics have demonstrated a high degree of competence in specific areas. Besides passing exams each mechanic must also have worked in the field for two or more years before a certificate is issued. These professional mechanics are fully able to analyze vehicle problems and perform the necessary service procedures to keep your Volvo at peak operating condition.
| Note that the above pertains to USA only. |
Your new Volvo comes with a four year road assistance program named ON-CALL. Additional information, features, and benefits are described in a separate information package in your glove compartment.
| pg. 9:9 Specifications |
Dimensions and weights
U.S.A. and Canada
Length (sedan)
188.4 in (487.1 cm)
Length (wagon)
190.7 in (484.4 cm)
width
69.3 in (175 cm)
Height, Sedan
55.5 in (141 cm)
Wagon
56.7 in (144 cm)
Wheelbase
109 in (277 cm)
Track, front
57.8 in (147 cm)
Sedan rear
59.8 in (152 cm)
Wagon rear
57.5 in (146 cm)
Turning circle, (between curbs)
32.5 ft. (9.9 m)
Trunk capacity (sedans)
17.2 cu. ft. (0.49 m
Cargo capacity (wagons)
with rear seat up
39.3 cu. ft. (1.1 m
)
with rear seat down
74.9 cu. ft. (2.1 m
)
Curb weight (sedan)
3497 lbs (1586 kg)
1585 kg
Curb weight (wagon)
3459 lbs (1569 kg)
1566 kg
Gross vehicle weight (sedan)
4440 lbs (2014 kg)
2015 kg
Gross vehicle weight (wagon)
4500 lbs (2041 kg)
2045 kg
Capacity Weight (sedan)*
930 lbs (422 kg)
420 kg
Capacity Weight (wagon)*
1045 lbs (475 kg)
475kg
Permissible axle weight, front (sedan)
2165 lbs (982 kg)
985 kg
front (wagon)
2135 lbs (968 kg)
970 kg
rear (sedan)
2325 lbs (1055 kg)
1055 kg
rear (wagon)
2420 lbs (1100 kg)
1100 kg
Max. roof load **
220lbs (100 kg)
Max. trailer weight (w/o brakes)
1540 lbs (700 kg)
Max. trailer weight (with brakes - 2" ball)
3300 lbs (1500 kg)
Max. trailer weight (with brakes - 1 7/8" ball)
2000lbs (908 kg)
Max. trailer tongue weight
165 lbs (75 kg)
See also section "Trailer hauling".
*
The max permissible axle loads or gross vehicle weight must not be exceeded.
Consult your Volvo retailer for information.
WARNING:
|
All specifications are subject to change without notice.
| pg. 9:10 Customer Support |
| Vehicle Information (see "Label information" section) |
| Vehicle License Number |
| Vehicle Identification Number (VIN) |
| Service Designation Number |
| Engine Designation (See "Specifications" section) |
| Color code |
| Upholstery |
| Tire designation (See "Tires" section) |
| Vehicle capacity |
Do not export your Volvo to another country before investigating that country's applicable safety and exhaust emission requirements. In some cases it may be difficult or impossible to comply with these requirements. Modifications to the emission control system(s) may render your Volvo not certifiable for legal operation in the U.S., Canada and other countries.
| Inside back cover |
|
WARNING!
Detergents and solvents Do not use gasoline containing lead or benzene as a detergent or solvent. Both lead and benzene are toxic and may be hazardous to your health. Installation of optional equipment/use of mobile telephones Incorrectly installed optional equipment, alarm systems or the use of mobile telephones which are not connected to a suitable antenna can cause faults in the car's electronic control systems. Your car is equipped with an accessory connector located under the dashboard on the driver's side. Please consult your Volvo retailer if you have any questions before connecting accessory or optional equipment to the vehicle's electrical systems. Carbon monoxide Carbon monoxide is a poisonous, colorless and odorless gas which is present in all exhaust gases. If you ever smell exhaust fumes from inside the vehicle, make sure the passenger compartment is ventilated and immediately return the vehicle to your retailer for correction. Never sit in a parked or stopped car for any extended amount of time, nor have it unattended while the engine is running. Never operate the engine in confined, unventilated areas. |
| Back Cover |
UNLEADED FUEL ONLY
VOLVO |
Octane rating, see p. 4:3.
Tire pressure, see label located on rear edge of right front door.
| Bulbs | Power | Socket | US Bulb No. |
| 1 | 45/65 W | 9004 | |
| 2 | 27 W | GE881 | |
| 3 | 5 W | BA 15s | 67 |
| 4 | 21 W | BA 15s | 1156 |
| 5 | 21/5 W | BAY 15d | 1157 |
VOLVO
Volvo Car Corporation
Goteborg, Sweden
TP 3515/2 (Canada & U.S.A.) 9000.10.93
